Paper Details

ANALYSIS AND COMPARISON OF VARIOUS PULSE WIDTH MODULATION STRATEGIES FOR HYBRID INVERTER WITH REDUCED NUMBER OF COMPONENTS

N. Susheela

Department of Electrical Engineering, University College of Engineering (A),Osmania University, Hyderabad, Telangana

12 - 26 Vol. 3, Jan-Dec, 2017
Receiving Date: 2017-01-02;    Acceptance Date: 2017-01-19;    Publication Date: 2017-01-23
Download PDF

Abstract

Performance of hybrid inverter with less number of components is presented in this paper. When compared to diode clamped, flying capacitors, and cascaded H-bridge multilevel inverters, the hybrid inverter requires fewer components, fewer carrier signals and gate drives. Therefore, the overall cost and complexity are greatly reduced particularly as the output voltage level increases. Implementation of single phase seven-level, ninelevel and eleven-level hybrid inverter have been performed using sinusoidal pulse width modulation (SPWM) techniques i.e., phase disposition (PD) and alternate phase opposition disposition (APOD). The total harmonic distortion (THD) is evaluated for various modulation indices using MATLAB/SIMULINK.

Keywords: sinusoidal pulse width modulation; hybrid inverter; alternate phase opposition disposition; phase disposition; total harmonic distortion;

    References

  1. Xiaoming Yuanand Ivo Barb, “Fundamentals of a New Diode Clamping Multilevel Inverter”, IEEE Transactions on Power Electronics, Vol.15, No.4, July 2000.
  2. Jih-Sheng Lai, IEEE, and Fang ZhengPeng, “A New Breed of flying Capacitor Multilevel Converter” IEEE Transactions On Industry Applications, VOL. 32, NO. 3, MAYIJUNE 1996
  3. Yun XU, Yunping ZOU, Xiong LIU, Yingjie He, “A Novel Composite Cascade Multilevel Converter”, IEEE Industrial Electronics Society (IECON), Nov. 5-8, 2007.
  4. G. M. Martins, J. A. Pomilio, S. Buso, and G. Spiazzi, “Three-phase low frequency commutation inverter for renewable energy systems,” IEEE Trans. Ind. Electron., vol. 53, no. 5, pp. 1522–1528, Oct. 2006.
  5. N.Susheela, P.Satish Kumar and C.H.Reddy, “Performance Analysis of Four Level NPC and NNPC Inverters using Capacitor Voltage Balancing Method” IEEE Uttar Pradesh Section International Conference on Electrical, Computer and Electronics Engineering (UPCON), pp. 212- 217, Dec 2016,doi:10.1109/UPCON.2016.7894654.
  6. G. S. Perantzakis, F. H. Xepapas, and S. N. Manias, “A novel four-level voltage source inverterinfluence of switching strategies on the distribution of power losses,” IEEE Trans. Power Electron., vol. 22, no. 1, pp. 149–159, Jan. 2007
  7. G. Mondal, K. Gopakumar, P. N. Tekwani, and E. Levi, “A reducedswitch- count five-level inverter with common-mode voltage elimination for an open-end winding induction motor drive,” IEEE Trans. Ind. Electron., vol. 54, no. 4, pp. 2344–2351, Aug. 2007
  8. N.Susheela, P.Satish Kumar and S.K.Sharma, “Mapping Method Based Space Vector Modulation Technique for Diode Clamped Multilevel Inverters” IEEE Uttar Pradesh Section International Conference on Electrical, Computer and Electronics Engineering (UPCON), pp. 410-415, Dec 2016. doi:10.1109/UPCON.2016.7894689
  9. S. G. Song, F. S. Kang, and S.J. Park, “Cascaded multilevel inverteremploying three-phase transformers and single dc input,” IEEE Trans.Ind. Electron., vol. 56, no. 6, pp. 2005–2014, Jun. 2009
  10. G. Ceglia, V. Guzman, C. Sanchez, F. Ibanez, J. Walter, and M. I. Gimenez, “A new simplified multilevel inverter topology for dc-ac conversion,” IEEE Trans. Power Electron., vol. 21, no. 5, pp. 1311–1319, Sep. 2006.
  11. N. A. Rahim, K. Chaniago, and J. Selvaraj, “Single-phase seven-level grid-connected inverter for photovoltaic system,” IEEE Trans. Ind. Electron., vol. 58, no. 6, pp. 2435–2443, Jun. 2011.
  12. J. Selvaraj and N. A. Rahim, “Multilevel inverter for grid-connected PV system employing digital PI controller”, IEEE Trans. Ind. Electron., vol. 56, no. 1, pp. 149–158, Jan. 2009.
  13. S. A. Gonzalez, M. I. Valla, and C. F. Christiansen, “Analysis of a cascade asymmetric topology formultilevel converters”, in Proc. IEEE ISIE, pp. 1027–1032, 2007
  14. P. Lezana and J. Rodriguez, “Mixed multicell cascaded multilevel inverter”, in Proc. IEEE ISIE, pp. 509–514, 2007.
  15. N.Susheela, P.Satish Kumar, B.Sirisha, “Hybrid Topologies of Multilevel Converter for Current Waveform Improvement”, International Journal of Inventive Engineering and Sciences (IJIES), ISSN: 2319–9598, Volume-1, Issue-4, pp.29-37, March, 2013
  16. N. Mohan, T. M. Undeland, and W. P. Robbins, Power Electronics: Converters, Applications, and Design, Second Edition, John Wiley and Sons, 1995.
  17. EhsanNajafi, and Abdul Halim Mohamed Yatim, “Design and Implementation of a New Multilevel Inverter Topology”, IEEE Transactions on Industrial Electronics, Vol. 59, No. 11, November 2012.
